CYY-W600 Large-Screen Molten Metal Thermometer

CYY-W600 is a dedicated large-screen molten metal temperature measuring device designed specifically for foundries and metallurgical plants requiring rapid liquid metal temperature monitoring in furnaces. This large-screen pyrometer utilizes direct insertion thermocouple technology to deliver high-precision temperature measurements.

During metal melting and casting, the temperature of molten iron, steel, and other molten metals is a critical parameter that must be monitored before pouring. The CYY-W600 is designed for use in furnace areas, at furnace outlets, or at any temperature monitoring point within the foundry, enabling operators to quickly determine the actual temperature of molten metal.

The CYY-W600 can be used to measure the temperature of molten iron, steel, copper, aluminum, and other molten metals. In international terms, these applications fall under foundry temperature measurement, molten metal temperature measurement, melting, and casting.

Large display designed for foundries: The CYY-W600 features a 5-inch screen with characters approximately 120mm tall and 66mm wide. This distinguishes it from handheld temperature meters. As per installation guidelines, the display can be positioned up to 10m away in a direct line of sight and mounted at a height of about 2-4m, providing a clear temperature viewing area on the shop floor.

Fixed-mount configuration: The CYY-W600 differs from the handheld meter in its mounting structure. This device is designed for wall mounting and connects via cable to the measurement gun, which supports a range of 1,6-3,3 meters depending on the model. This setup is ideal for enterprises seeking a fixed temperature monitoring point near furnace areas.

Quick measurement within 3 seconds: The CYY-W600 is designed for rapid in-shop measurements. Follow the instructions to insert the probe into molten metal; typical measurement time is 3-5 seconds. When the measurement beep ends, the operator removes the gun from the molten metal. The device then displays a stable temperature value on the screen.

Do not leave the probe in molten metal for too long. The manual specifies that the probe should remain immersed for no more than 7 seconds to prevent damage to the thermocouple paper tube and related components.

Mid-frequency induction furnace temperature measurement: For workshops using mid-frequency induction furnaces, electrical noise is a key consideration when selecting a temperature measuring device. The CYY-W600 is designed with robust anti-interference measures. According to the manual, this device can perform measurements inside an active mid-frequency furnace without requiring power shutdown. This practical feature is ideal for foundries operating induction melting furnaces, cupolas, steel melting furnaces, copper melting furnaces, and other induction smelting systems.

Monitor furnace area temperature: Another advantage of the large screen is its ability to support real-time operation monitoring. Product documentation states that the large-screen design enables visibility into worker activities on-site, helping businesses strengthen internal management. This is especially suitable for workshops with many furnace operators, multiple production shifts, and supervisors overseeing the smelting area.

Key Features: 1. Large temperature display — 120mm, tall characters for easy remote viewing 2. Auto hold — Temperature value is retained on the display after measurement 3. Completion alarm — Audible alert when measurement ends 4. Thermocouple error — Alerts if thermocouple is broken 5. Range over-limit — Warns when signal exceeds measurement range 6. Noise immunity — Designed for metallurgical environments and medium-frequency induction furnaces

Rapid Thermocouple — System Accessory: CYY-W600 requires a compatible rapid thermocouple for measurement. The rapid thermocouple is a contact sensor that measures liquid metal temperature and transmits the signal to CYY-W600. When ordering, specify the material type (e.g., molten iron, steel, or copper) and temperature range to ensure the correct configuration.

CYY-W600 is suitable for: iron foundries, steel foundries, metallurgical plants, metal melting workshops, copper foundries, aluminum foundries, mechanical casting workshops, induction furnace facilities, medium-frequency furnace shops, and production lines requiring temperature checks before pouring.

The device is CE-certified, features a fully English control panel, and meets international standards. To align with diverse customer search patterns, this product may also be referred to as: Large-screen molten metal pyrometer, Foundry furnace temperature meter, Pre-furnace temperature gauge, Casting furnace thermometer, Smelting furnace temperature sensor, or Wall-mounted molten metal pyrometer.
